SKF SM 42 -SS vibracon adjustable chock
- Brand
- SKF
- Category
- Mounting and maintenance tools
- Subcategory
- Mounting and maintenance tools
We reply promptly.
Tell us the quantity you need and request a quote by WhatsApp or email.
Can't find the exact model? Tell us the part number or model you need. We'll track it down and quote it, whether or not it appears in our catalog.
Description
SKF SM 42 -SS belongs to vibracon adjustable chock, part of our Mounting and maintenance tools range. Tell us how many you need by WhatsApp or email and we'll get back to you promptly with a quote for SM 42 -SS and any equivalents.
SKF Vibracon SM -SS chocks are adjustable supports made of carbon steel, placed between a machine base and its foundation to correct unevenness and hold equipment level before final anchoring. They take the place of conventional sheet metal shims. The series is supplied for plant and workshop installations across the United States, Canada, Mexico and South America.
Reading the code is straightforward. The figure after SM gives the chock size, so SM 16 -SS, SM 20 -SS, SM 24 -SS, SM 30 -SS and SM 42 -SS each sit in a different height and capacity range. The -SS ending marks the carbon steel version. When you ask for a quote, include the full part number plus the dimensions of the machine being leveled so the right size can be confirmed.
Typical applications are pumps, motors, compressors, gearboxes and rotating equipment in general. Food, chemical and petrochemical plants use them, as do metalworking shops where stable, fine leveling matters. They fit new installations and also serve as replacements for metal shims during maintenance shutdowns.
Selection comes down to three items: the load carried by each support point, the leveling height required, and the anchoring method. During installation the equipment is aligned and the anchor bolts are tightened in stages. The support surface has to be clean and flat. After leveling, the chock is secured and alignment is checked once more before start-up.
Vibracon SM -SS chocks can be swapped with adjustable chocks from other manufacturers when the dimensions are similar, but height, bolt diameter and load capacity should always be verified first. There is no universal cross-reference, since every manufacturer works to its own dimensions. If you have the old part number, send it and the corresponding SKF reference can be identified.
To request a quote for Vibracon SM -SS chocks, message the part number and your equipment details on WhatsApp or by email. The team replies promptly, can suggest equivalents and helps with the selection.
Dimensions
Dimensions and tolerances: Message us the part number on WhatsApp and we'll verify its dimensions and version with the manufacturer's datasheet.
Frequently asked questions
- What does the -SS suffix mean in Vibracon SM?
- It identifies the carbon steel variant within the Vibracon line. Dimensions and capacity stay the same; only the material differs. Send the complete part number and the exact version can be confirmed.
- How do I choose the Vibracon SM size I need?
- Base the choice on the load per support, the leveling height and the anchor bolt diameter. With those figures a model can be recommended. If a part number is already on hand, send it and the equivalent in the SM -SS line can be located.
- Are Vibracon SM -SS suitable for leveling pumps and motors?
- Yes. They are used for pumps, motors, compressors and other rotating equipment, sitting between the machine base and the foundation so height can be adjusted precisely before final anchoring. Share your application details and the team can advise.
