LINK-BELT PT3U2E20N pillow block bearing
- Brand
- LINK-BELT
- Category
- Bearing housings
- Subcategory
- Bearing housings
- Series
- 200
We reply promptly.
Tell us the quantity you need and request a quote by WhatsApp or email.
Can't find the exact model? Tell us the part number or model you need. We'll track it down and quote it, whether or not it appears in our catalog.
Description
LINK-BELT PT3U2E20N belongs to pillow block bearing, part of our Bearing housings range. Tell us how many you need by WhatsApp or email and we'll get back to you promptly with a quote for PT3U2E20N and any equivalents.
Link-Belt PT3U2E pillow blocks are two-bolt mounted bearing units that fasten to a flat base and carry a rotating shaft. They suit power transmission and conveying duty where the support has to stay rigid and alignment has to be straightforward. MR Industrial Accessories LLC supplies this line, and the part number sets the shaft size.
The code breaks down into segments. PT stands for the pillow block type. The 3 covers the housing design. U means the unit comes with an inserted bearing. The 2 places it in the 200 dimensional series. E identifies the sealing type, and N identifies how the inner ring locks. In PT3U2E20N and PT3U2E32N, the digits 20 and 32 give nominal shaft diameters in millimeters, so the same housing family covers a range of shaft sizes.
Typical duty includes belt and roller conveyors, mixers, mills, bucket elevators and packaging lines. Plants running this type of equipment deal with dust, humidity or frequent washdowns, and the 200 series sits in the medium-duty part of the mounted bearing range, which fits moderate loads and the speeds normally found in standard power transmission drives.
Selecting the right unit comes down to three things: shaft diameter, whether the load is radial, axial or combined, and the environment around the bearing. The E seal handles dust and splashes. Where high-pressure washdown is routine, look at extra protection. Mounting calls for a flat, rigid base with the holes lined up and bolts tightened evenly. Regrease on the duty cycle, and set internal clearance when the inner ring is locked with the N system.
For a replacement, do not match on part number alone. Check the base dimensions, the height to the shaft center and the shaft diameter. A series from another manufacturer can differ in sealing or locking even when the numeric designation looks the same. Send the full part number and the main dimensions, and the team can point you to a compatible option.
Dimensions
- Bore
- 1 1/4 in
Frequently asked questions
- What does the part number PT3U2E20N tell me?
- PT is the pillow block type, 3 is the housing design, U is the unit with bearing, 2 is the 200 dimensional series, E is the sealing type and N is the locking system. The 20 is the nominal shaft diameter in millimeters.
- How do I check whether this pillow block fits my machine?
- Measure the shaft diameter, the distance between the base holes and the height to center. Those dimensions decide fit, not the part number alone. Send them by WhatsApp or email and the team will confirm a compatible alternative.
- What maintenance does this type of pillow block need?
- Check bolt tightness, seal condition and lubrication on a regular schedule. In dusty or humid areas, inspect more often and renew the grease according to how the equipment runs.
