LINK-BELT FB224M25H flange bearing 3 holes

LINK-BELT FB224M25H belongs to flange bearing 3 holes, part of our Bearing housings range. Tell us how many you need by WhatsApp or email and we'll get back to you promptly with a quote for FB224M25H and any equivalents.

A three-bolt flange bracket from the Link-Belt B22400 series pairs an insert bearing with a flanged housing, giving you a bolt-on mounting point for a rotating shaft. It suits walls, frames and steel structures where there is little room to work and the shaft has to sit square and stay put. MR Industrial Accessories LLC supplies this line to customers in the United States and Latin America.

The code tells you most of what you need. FB stands for the three-bolt flange, 224 is the size inside the B22400 series, M marks the metric mounting arrangement, and H identifies the insert bearing. That is why FB224M25H, FB224M30H and FB224M35H use the same housing and differ only in the shaft diameter they take. Once you know how the code is built, you can order a replacement without pulling the unit apart first.

You will find these brackets on belt conveyors, bucket elevators, mixers, screens and process lines in food, chemical and aggregate plants, including material handling equipment and machines running long shafts under moderate radial loads. The three-bolt pattern lets you anchor the flange to sheet metal or structural profiles with a layout that holds against torque.

Before ordering, confirm the shaft diameter, the operating speed and the surrounding conditions. In dusty or wet areas, specify the right sealing; where the shaft grows with temperature, check the internal clearance. When you mount the unit, seat the flange on a flat surface, tighten the three bolts in a cross pattern, and align the shaft before final tightening. Grease it according to the insert type and check clearance and seal condition on a regular schedule.

Mounted brackets can be swapped between brands if the part number, flange dimensions, shaft diameter and hole spacing line up. Matching the diameter alone is not enough: compare the overall height, the insert style and the way the shaft is locked. The goal is dimensional equivalence with the other line, and our team can point you to the compatible option.

To replace a three-bolt flange bracket, send the full part number by WhatsApp or email. With FB224M25H, FB224M30H or FB224M35H in hand, we will quote the part and, where it applies, suggest the alternative that fits your equipment. We also take inquiries based on flange dimensions and shaft diameter for special cases.
